E-NR: 6332819
MC 470
High Security Contact, Surface mount, NC
MC 470 is a surface mount high security contact with NC function with 6 screw connections and sabotage contact. The contact is specially designed for use in banks, museums, art galleries, stores, etc.
It has screw terminals with wire protection and a sabotage contact. Enclosed are plastic spacers for installation on steel.
The contact can be supplemented with different accessories such as brackets and extra strong magnets.
| Attributes | Value |
|---|---|
| Approvals |
Class 3/4,F&P, class II, CNPP 2134030003C0, EN 50131-2-6 Grade 3, FG, GRADE 3 + RTC, INCERT B-582-1003, NBÚ CZ Typ 3, NBÚ SK Typ 3, NF&A2P, SBSC 9-201 |
| Contact rating |
48 VDC / 500 mA / 10 VA |
| Operating temperature |
-40°C – +70°C |
| Housing protection class |
IP 43 |
| Make distance (wood) mm |
27 |
| Make distance (steel) mm |
10 |
| Contact dimensions (L x W x H) mm |
65 x 20 x 15 |
| Magnet dimensions (L x W x H) mm |
65 x 14 x 10 |
| Normal operation |
12 VDC |
| Grade |
3 |
| Product type |
Detectors |
| Environment |
Indoor |
| Mounting type |
Surface-mounted |
| Product group |
Magnetic contact |
| Product feature |
Surface-mounted |
| Application area | |
| Security certification and approval schemes |
EN, F&P, FG, INCERT, NBU, NF&A2P, SBSC |
| Security class |
3 |
| Environmental class |
II |
| Product name | E-nr | Description |
|---|---|---|
| MC 470 | 6332819 | High security contact, NC, surface mount |
| MC 470-B | 6332891 | High security contact, NC, surface mount, brown |
